| Part # |
Description |
Item # |
Dexter # |
| 27-442 |
LH Complete Brake Assembly |
Assembly |
023-105-00 |
| 27-443 |
RH Complete Brake Assembly |
Assembly |
023-106-00 |
| |
|
1 |
|
| 27-492-1 |
LH Actuating Lever Arm Assembly |
2 |
047-107-00 |
| 27-493-1 |
RH Actuating Lever Arm Assembly |
2 |
047-108-00 |
| 27-509-1 |
Wire Clip |
3 |
027-005-00 |
| 27-500 |
Retractor Spring |
4 |
046-009-00 |
| |
|
|
|
| 27-401 |
Shoe & Lining Kit Contains |
5 |
K71-048-00 |
| |
Primary Shoe & Lining |
5 |
040-044-00 |
| |
Secondary Shoe & Lining |
5 |
040-045-00 |
| 27-513-1 |
Shoe Hold Down Pin #2 |
5 |
049-011-00 |
| 27-514 |
Shoe Hold Down Spring & Cup |
5 |
046-077-00 |
| |
|
|
|
| 27-510 |
Adjuster Assembly |
6 |
043-004-00 |
| 27-511 |
Adjusting Screw Spring |
7 |
046-018-00 |
| |
|
|
|
| 27-421 |
Magnet Kit Contains |
8 |
021-003-00 |
| |
Magnet (white wire) |
8 |
042-099-01 |
| 27-499 |
Magnet Clip |
8 |
027-009-00 |
| 27-499-1 |
Magnet Spring |
8 |
046-080-00 |
| |
|
|
|
| 27-512 |
Adjuster Slot Plug |
9 |
046-007-00 |
| 27-509 |
Wire Grommet |
10 |
046-016-00 |
| 27-504 |
Anchor Post Washer |
11 |
005-067-00 |
| 27-062-4 |
Nut Washer Assembly |
12 |
006-193-00 |
| |
(not included with complete brake assembly) |
|
|
| 27-062-2 |
Brake Stud Mount |
Not Shown |
007-112-00 |
| 27-442-1 |
12” LH Complete Brake Assembly 9-Hole |
Not Shown |
K23-105-09 |
| 27-443-1 |
12” RH Complete Brake Assembly 9-Hole |
Not Shown |
K23-106-09 |
| 27-427 |
Kelsey 10” Magnet |
Not Shown |
5105 |
